Home > Products > Laser Cutting > CO2 Laser Cutting Machine
Laser cut machine polymer clay engraving
With a reasonable size, the laser cutter is really good for users who have very little space to put the machine.
Though the size is small, its ability for cutting and engraving is also as good as the big machines.
It’s especially good for customers who need to make customized products.
This belt is stable performance with long life, wearable and durable.
High quality rails
Keep the engraving/cutting precise and very durable.
Standard laser head
It is the most often used head.
Hybrid servo motor
1000mm/s speed for engraving photo, super smooth vector cutting quality.
Honey comb table
Reduces underside reflections.
Set speed, power, and more directly from the LCD panel.
USB disk interface
Chanxan laser system supports the USB disk loading.
Low-noise cooling fan
Operate the laser in a quiet and comfortable surroundings.
keep the temperature to ensure the stability of laser working.
Ensure the work pieces and laser cutter machine inside be clean.
Blowing air to prevent the material being burned.
Designed with the home hobbyist in mind, this easy-to-use upgraded mini 40W CO2 laser engraver delivers professional results. This powerful cutting machine is equipped with a 40W water cooling laser tube, high-precision stepper motors and a top-quality control board.
If your material is not in the below list, our Applications Team would be happy to assist you to test it.
* means the laser cannot engrave directly, you will need the help of the “thermark spray”.
|Laser Tube Wattage||40Watt|
|Max Part Size (WxLxH)||Front door closed|
700x530x170mm(27.6″ x 20.9″ x6.7″)
700x∞x15mm(27.6″ x ∞” x 0.6″)
|Table Size||700x530mm(27.6″ x 20.9″)|
|Z Axis Height||155mm(6.1″)|
1070x810x610mm(42.1″ x 31.9″ x24″)
|Laser Type||Sealed Co2 Glass Laser Tube|
|Motion Control System||High-Speed Hybrid servo motor|
|Maximum Speed||1000mm/S(39.4 IPS)|
|Speed and Power Control (engraving depth)||Computer or manually controlled speed and power from 0-100%. Vector color mapping sets speed and power settings using RGB color mapping.|
|Operating Modes||Optimized raster, vector, and combined mode|
|Resolution(DPI)||User controlled from 100 to 500DPI(standard laser head), up to 1000 DPI(HR head)|
|Computer Interface||Ethernet and USB Connection|
|Compatible Operating Systems||Windows XP/2000/Vista/7/8/10|
|Buffer Memory||128MB Standard|
|Display Panel||3.5″ LCD panel showing current file, total working time, laser power, speed etc.|
|Electrical Requirements||110 to 240 volts, 50 or 60 Hz, single phase|
|Ventilation System||Integral exhaust fan.There is 1 output port, 5.7″ (145 mm) in diameter in the rear of the case.|
It is widely used in seal/stamp engraving, electronic, craft and gift, garment, leather, toy, computerized embroidery, packing and printing, shoemaking, furniture, advertising industries ect.
Suitable to rubber, plastic, crystal, Plexiglas, acrylics, bamboo and wooden, marble, granite,ceramic, glass, china, paper, garment, jade article, glass, shell and other non-metal materials.
bookmark laser cut
plexiglass laser etching
wood laser engraving
